IGSFP-SD-S-LC-1310T/1550R-40-DDM

Name: IGSFP-SD-S-LC-1310T/1550R-40-DDM
Brand: Kyland
SKU: 09826300
Availability: InStock

Kyland

Price on request

Gigabit SFP module, Single fiber bi-direction, single mode, 1310T/1550R, 40km, LC connector,, DDM, -40...+85C, 3.3 V

Description

Specification

Ethernet
Total Ethernet	1
10/100/1000 Mbit/s	1
Type 10/100/1000 Mbit/s	LC Duplex
SFP module type	Single fiber. WDM
SFP 100/1000 Mbit Ports	1
Fiber
Number of Optical Ports	1xLC Duplex
Type of Fibre Optic	single-mode
Transmission Range	40 km
Length Wave RX	1550 nm
Length Wave TX	1310 nm
Supported Protocols
IEEE Standard	ieee_802.3
Construction
Construction Chassis	Metal Chassis
Protection Level of Chassis	IP20
Dimensions and weight
Width	13.9 mm
Depth	58.4 mm
Height	12.6 mm
Operating Conditions
Operating Temperature	-40...85 °C
Humidity	5-95%
Standards and Certifications
EMI	EN 55022, CISPR 22 Class
EMS	IEC 61000-4-4, IEC 61000-4-2

Files
