Specification
Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Built-in |
Digital Output | |
| Total channels of digital output | 8 |
| Sink/Source | Source |
| Max. load current | 1500 mA |
| Output voltage | 24~110 V |
Operating Conditions | |
| Operating Temperature | -40...75 °C |
Standards and Certifications | |
| EMI | FCC Part 15 Subpart B Class A, CISPR 32 |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN 55024, EN 61000-6-2, EN 61000-6-4, EN 55032 |
| Rolling Stock | EN 50121-4, EN 50155 |
| Safety | UL 508 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
