Specification
Analog Input | |
| Total channels of analog input | 1 |
| Voltage range | 0...100 mV |
Analog Output | |
| Channels of analog input | 1 |
| Voltage range | 0...5 V |
Connectors | |
| Connectors | Pin Header |
System Power Input | |
| Input Voltage DC | 5...5 V |
Dimensions and weight | |
| Width | 41.9 mm |
| Depth | 10.2 mm |
| Height | 28.1 mm |
Operating Conditions | |
| Operating Temperature | -40...85 °C |
Standards and Certifications | |
| Certifications | CE |
| EMI | EN 61000-6-4 |
| EMS | IEEE C37.90.1, EN 61000-6-2 |
| Oil And Gas | Class I Div.2 Groups A, B, C, D |
