Specification
System Architecture | |
| System Bus | ISA |
Analog Input | |
| Total channels of analog input | 16 |
| Single-Ended channels | 16 |
| Differential channels | 8 |
| Number of Bits | 12 Bit |
| Sampling rate | 125 Hz |
Analog Output | |
| Channels of analog input | 2 |
| Voltage range | 0...5 V, 0...10 V, +/-10 V |
Digital Input | |
| Total channels of digital input | 16 |
| Type | Wet contact |
| Level of Logic "0" | 0~0.8 V |
| Level of Logic "1" | 2~5 V |
| Number of channels | 3 |
| Counter capacity | 16 Bit |
| Max frequency | 10 kHz |
Digital Output | |
| Total channels of digital output | 16 |
| Sink/Source | Sink, Source |
| Output voltage | 0~5 V |
| Max. load current | 0.8 mA |
Connectors | |
| Internal Ports | 2x20-pin box header |
| Connectors | DB37 Female |
Software | |
| Operating System Compatibility | Linux kernel 2.6, Windows XP, Windows 7, Windows Vista |
| Development Software | VC, VB, Delphi, BCB, LabVIEW |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
