Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Built-in, Desktop, Wall |
| Type | Fanless |
CPU | |
| CPU Support Type | Core i7, Core i5, Core i3, Celeron |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| Maximum Memory | 32 GB |
Graphic | |
| Graphic Controller | Nvidia GeForce GTX 1050 Ti |
Ethernet | |
| Total Ethernet | 10 |
| 10/100/1000 Mbit/s | 10 |
Interfaces | |
| COM Total | 3 |
| RS-232/422/485 | 3 |
| USB Total | 4 |
| USB v3.x | 4 |
Drive interfaces | |
| RAID Levels | 1, 5 |
| mSATA | 1 |
Storage Cage | |
| 2.5" Cage Intenal | 2 |
Extension Slots | |
| Total | 4 |
| M.2 | 1 |
| Mini-PCIe/Mini Card | 3 |
| SIM Card slots | 2 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | 3xDB9, 4xUSB, Mic In, Line In, Line Out, 10xRJ45 Ethernet |
System Power Input | |
| Input Voltage DC | 9...48 V |
Dimensions and weight | |
| Width | 260 mm |
| Height | 250 mm |
| Depth | 95 mm |
Operating Conditions | |
| Operating Temperature | -40...70 °C |
| Vibration | 2.5G at 5~500Hz. 1hr/axis with SSD |
| Shock | Trucks and semi-trailers=15G (11ms) with SSD |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
| MIL-STD-810 | MIL-STD-810G Test Method 514.6 Vibration, MIL-STD-810G Test Method 516.6 Shock |
| Vehicle | E-Mark |
