Construction | |
| Construction Chassis | Metal Chassis with Aluminium Heatsink |
| Mounting Configuration | Wall |
| Type | Fanless |
CPU | |
| СPU Generation/Family | Comet Lake |
| Socket | LGA1200 |
| CPU Support Type | Celeron, Core i3, Core i5, Core i7, Core i9 |
Chipset | |
| Chipset | Intel Q470E |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM 260-pin |
| ECC | No |
| Maximum Memory | 64 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
| Interfaces | 2xDisplayPort |
Ethernet | |
| Controller Type | Intel i211-AT 10/100/1000 Mbps, Intel i219-LM |
| Total Ethernet | 8 |
| PoE 10/100/1000 Mbit/s | 8 |
Interfaces | |
| COM Total | 4 |
| RS-232/422/485 | 4 |
| USB Total | 8 |
| USB v3.x | 8 |
Digital Input-Output | |
| Channels of DIO | 12 |
Drive interfaces | |
| SATA 3 | 1 |
Storage Cage | |
| 2.5" Cage Intenal | 1 |
Extension Slots | |
| Total | 7 |
| M.2 | 5 |
| M.2 Form Factor | 2280 M, 3042 B, 3052 B, 2230 E |
| Mini-PCIe/Mini Card | 2 |
| SIM Card slots | Yes, 2 |
Antenna characteristics | |
| Cellular interfaces | 4G (Optional) |
LED / Controls | |
| LED | 1xHDD LED |
| Controls | On/Off |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | 4xDB9, 8xUSB, Mic In, Line Out, 2xDisplayPort, DC input (terminal block), DB15 GPIO, 2xSIM Card Slot, 8xRJ45 Ethernet |
System Power Input | |
| Input Voltage DC | 9...60 V |
Power Supply | |
| Supported Types of Power Supply | External power adapter AC/DC |
Software | |
| Operating System Compatibility | Windows 11, Windows IoT Enterprise 10, Ubuntu 20.04 |
Dimensions and weight | |
| Width | 242 mm |
| Height | 85 mm |
| Depth | 240 mm |
Operating Conditions | |
| Operating Temperature | -40...70 °C |
| Humidity | 10-90% |
| Vibration | IEC 60068-2-64. Random. 2.5G@5~500Hz. 1hr/axis MIL-STD-810G. Method 514.6. Procedure I. Cat.4. Operating |
| Shock | Operating: MIL-STD-810G. Method 516.6. Procedure. Trucks and semi-trailers=15G (11ms) with SSD |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
| MIL-STD-810 | MIL-STD-810G Test Method 514.6 Vibration, MIL-STD-810G Test Method 516.6 Shock |
