Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | DIN-Rail mount |
Interfaces | |
| RS-485 | 1 |
Supported Protocols | |
| Industrial Protocols | Modbus RTU slave, Advantech slave |
Expansion Module | |
| io_type | temperature |
Analog Input | |
| Total channels of analog input | 8 |
| Number of Bits | 16 Bit |
| Current range | 4...20 mA, -20...+20 mA |
| Sampling rate | 10 Hz |
| Differential channels | 8 |
| Thermocouple | J: 0...+750 °С, T: -100...+400°C, K: 0...+1200°C, R: +500...+1750°C, E: 0...+1000°C, S: +500...+1750°C, B: +500...+1800°C |
Connectors | |
| Connectors | Screw Terminal |
Additional Functions | |
| Watchdog timer type | Hardware |
System Power Input | |
| Input Voltage DC | 10...30 V |
Dimensions and weight | |
| Width | 70 mm |
| Depth | 30 mm |
| Height | 112 mm |
Operating Conditions | |
| Operating Temperature | -10...70 °C |
