Specification
Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | DIN-Rail mount |
Interfaces | |
| RS-485 | 1 |
Supported Protocols | |
| Industrial Protocols | Modbus RTU slave, Advantech slave |
Expansion Module | |
| io_type | relay |
Digital Output | |
| Total channels of digital output | 8 |
| Type | Electromagnitic relay |
| Relay (Form A) | 4 |
| Contact rating of relay (Form A) | 05A@120V AC, 0.25A@250V AC, 1A@30V DC |
| Relay (Form C) | 4 |
| Contact rating of relay (Form C) | 0.25A@250V AC, 0.5A@120V AC, 1A@30V DC |
Connectors | |
| Connectors | Screw Terminal |
Additional Functions | |
| Watchdog timer type | Hardware |
System Power Input | |
| Input Voltage DC | 10...30 V |
Dimensions and weight | |
| Width | 70 mm |
| Depth | 30 mm |
| Height | 112 mm |
Operating Conditions | |
| Operating Temperature | -10...70 °C |
