Specification
Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | DIN-Rail mount |
Interfaces | |
| RS-485 | 1 |
Supported Protocols | |
| Industrial Protocols | Modbus RTU slave, Advantech slave |
Expansion Module | |
| io_type | temperature |
Analog Input | |
| Total channels of analog input | 6 |
| Number of Bits | 16 Bit |
| Sampling rate | 10 Hz |
| Differential channels | 6 |
| Thermal resistance | Pt100, Pt1000, Balco 500, Ni50, Ni508 |
Connectors | |
| Connectors | Screw Terminal |
Additional Functions | |
| Watchdog timer type | Hardware |
System Power Input | |
| Input Voltage DC | 10...48 V |
Dimensions and weight | |
| Width | 70 mm |
| Depth | 30 mm |
| Height | 112 mm |
Operating Conditions | |
| Operating Temperature | -40...85 °C |
