Specification
Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | DIN-Rail mount |
Interfaces | |
| RS-485 | 1 |
Supported Protocols | |
| Industrial Protocols | Modbus RTU slave, Advantech slave |
Expansion Module | |
| io_type | di_do |
Digital Input | |
| Total channels of digital input | 7 |
| Type | Dry contact, Wet contact |
| Level of Logic "0" | 0~3 V |
| Level of Logic "1" | 10~30 V |
| Sink/Source | Sink, Source |
| Number of channels | 7 |
| Counter capacity | 32 Bit |
| Max frequency | 3 kHz |
Digital Output | |
| Total channels of digital output | 8 |
| Type | Open collector |
| Sink/Source | Sink |
| Output voltage | 0~40 V |
| Max. load current | 1000 mA |
| Channels | 8 |
| Signal Type | PWM: Source |
| Output frequency range | 0~1 kHz |
Connectors | |
| Connectors | Screw Terminal |
Additional Functions | |
| Watchdog timer type | Hardware |
System Power Input | |
| Input Voltage DC | 10...48 V |
Dimensions and weight | |
| Width | 70 mm |
| Depth | 30 mm |
| Height | 112 mm |
Operating Conditions | |
| Operating Temperature | -40...85 °C |
