Specification
Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
Ethernet | |
| 10/100 Mbit/s | 1 |
Supported Protocols | |
| Industrial Protocols | Modbus TCP server, MQTT client |
Expansion Module | |
| io_type | multifunctional |
Analog Input | |
| Total channels of analog input | 8 |
| Number of Bits | 16 Bit |
| Voltage range | +/-150 mV, +/-500 mV, +/-1 V, +/-5 V, +/-10 V, 0...500 mV, 0...1 V, 0...5 V, 0...10 V |
| Current range | 0...20 mA, 4...20 mA, -20...+20 mA |
| Sampling rate | 100 Hz |
| Differential channels | 8 |
Digital Output | |
| Total channels of digital output | 2 |
| Type | Open collector |
| Sink/Source | Sink |
| Output voltage | 0~30 V |
| Max. load current | 100 mA |
Connectors | |
| Connectors | Screw Terminal |
Additional Functions | |
| Watchdog timer type | Hardware, Software |
System Power Input | |
| Input Voltage DC | 10...30 V |
Dimensions and weight | |
| Width | 70 mm |
| Depth | 27 mm |
| Height | 122 mm |
Operating Conditions | |
| Operating Temperature | -40...75 °C |
