Specification
Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
Digital Input | |
| Total channels of digital input | 6 |
| Type | Dry contact, Wet contact |
| Level of Logic "0" | 0~3 V |
| Level of Logic "1" | 10~30 V |
| Sink/Source | Sink, Dry: Source |
| Max frequency | 3 kHz |
| Counter | 3KHz |
Digital Output | |
| Total channels of digital output | 6 |
| Type | Electromagnitic relay |
| Relay (Form A) | 6 |
| Contact rating of relay (Form A) | 5A@250V AC, 3A@30V DC |
Expansion Module | |
| io_type | di_do |
Supported Protocols | |
| Industrial Protocols | Modbus TCP server, MQTT client |
Connectors | |
| Connectors | Screw Terminal |
Additional Functions | |
| Watchdog timer type | Hardware, Software |
System Power Input | |
| Input Voltage DC | 10...30 V |
Dimensions and weight | |
| Width | 70 mm |
| Depth | 27 mm |
| Height | 122 mm |
Operating Conditions | |
| Operating Temperature | -40...70 °C |
