Construction | |
| Construction Chassis | Metal Chassis with Aluminium Heatsink |
| Mounting Configuration | Wall, DIN-Rail mount |
| Type | Fanless |
CPU | |
| Processor Installed | ARM Cortex A78AE |
| Socket | CPU onboard |
Chipset | |
| Chipset | SoC |
Memory | |
| Form-factor | DDR5 |
| Socket Type | Soldered |
| ECC | No |
| Default on Board Memory | 32 GB |
| Assembly | Fixed on Board |
Graphic | |
| Graphic Controller | NVIDIA Ampere, 1792-cores, 56 Tensor Cores |
| Interfaces | HDMI |
Ethernet | |
| Total Ethernet | 6 |
| 10/100/1000 Mbit/s | 2 |
| PoE+ 10/100/1000 Mbit/s | 4 |
Interfaces | |
| COM Total | 2 |
| RS-232/422/485 | 2 |
| USB Total | 7 |
| USB 2.0 | 2 |
| USB v3.x | 5 |
Digital Input-Output | |
| Channels of DIO | 16 |
Digital Input | |
| Isolation DIO | Yes |
Industrial Interfaces | |
| CAN Port | 2 |
Drive interfaces | |
| M.2 | 2 |
| MicroSD | 1 |
Installed drive | |
| Drive Type | SSD |
| Storage Form-Factor | eMMC |
| 1st Storage Capacity | 64 GB |
Extension Slots | |
| Total | 5 |
| PCI Express x8 | 1 |
| M.2 | 4 |
| M.2 Form Factor | 2280 M, 3052 B, 3042 B, 2230 E |
| SIM Card slots | Yes, 2 |
Connectors | |
| Connectors | 2xDB9, HDMI, 5xUSB, DC input (terminal block), DIO (terminal block), CAN (terminal block), MicroSD card slot, 2xSIM Card Slot, Console Port Micro USB, 6xRJ45 Ethernet |
System Power Input | |
| Input Voltage DC | 9...48 V |
Power Supply | |
| Supported Types of Power Supply | External power adapter AC/DC |
Software | |
| Operating System Compatibility | Linux OS |
Dimensions and weight | |
| Width | 260 mm |
| Height | 182 mm |
| Depth | 69 mm |
Operating Conditions | |
| Operating Temperature | -25...70 °C |
| Humidity | 5-95% |
| Vibration | Operating. MIL-STD-810G. Method 514.6. Procedure I. Category 4 |
| Shock | Operating. MIL-STD-810G. Method 516.7. Procedure I |
Standards and Certifications | |
| Certifications | CE/FCC |
| Rolling Stock | EN 50155, EN 50121-3-2 |
