Construction |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Desktop, 19" Rackmount, Panel, Wall, Wall VESA 75 |
| Protection Level of Front Side (Panel) | IP65 |
| Type | Fanless |
Display |
| Display Type | LCD TFT |
| Diagonal | 7 " |
| Maximum resolution | 1024x600 Dots |
| Brightness | 500 Cd/m2 |
| Contrast Ratio | 700~1 |
Touch Screen |
| Touch Screen Type | Capacitive |
CPU |
| Processor Installed | Intel Celeron N2807 |
| Max CPU frequency | 2.16 GHz |
Memory |
| Form-factor | DDR3L |
| Default on Board Memory | 2 GB |
Graphic |
| Graphic Controller | Integrated in CPU |
Ethernet |
| Controller Type | Realtek RTL8111E PCIe GbE |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Wi-Fi |
| Wi-Fi Standard | 802.11b/g/n |
Interfaces |
| COM Total | 2 |
| RS-232 | 2 |
| USB Total | 2 |
| USB v3.x | 2 |
Drive interfaces |
| mSATA | 1 |
LED / Controls |
| LED | Power LED |
| Controls | On/Off, 1xReset, AT/ATX Switch |
Connectors |
| Connectors | DB9, RJ45, 2xRJ45 Ethernet, 2xUSB, DC Input |
System Power Input |
| Input Voltage DC | 9...30 V |
Power Supply |
| Type of Power Supply | External power adapter AC/DC |
| Output Power | 36 W |
Software |
| Operating System Compatibility | Windows 7, Windows Embedded Standard 7, Windows 8, Windows Embedded Standard 8, Linux kernel 3.x, Windows 8.1, Windows 10 |
Dimensions and weight |
| Width | 190.7 mm |
| Height | 127 mm |
| Depth | 38.9 mm |
Operating Conditions |
| Operating Temperature | -10...45 °C |
Standards and Certifications |
| Certifications | CE, FCC |
