Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Wall VESA 75 |
| Protection Level of Front Side (Panel) | IP64 |
| Type | Fanless |
Display | |
| Display Type | LCD |
| Diagonal | 8 " |
| Maximum resolution | 1280x800 Dots |
| Aspect Ratio | 16:10 |
| Brightness | 420 Cd/m2 |
| Contrast Ratio | 700~1 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| СPU Generation/Family | Elkhart Lake |
| Processor Installed | Intel Celeron J6412 |
| Max CPU frequency | 2.6 GHz |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| Default on Board Memory | 8 GB |
Ethernet | |
| Controller Type | Intel i225V, Intel i226V |
| Total Ethernet | 2 |
| 2,5 Gbit/s | 2 |
Interfaces | |
| COM Total | 2 |
| RS-232/422/485 | 2 |
| USB Total | 3 |
| USB 2.0 | 1 |
| USB v3.x | 2 |
Drive interfaces | |
| M.2 | 1 |
Extension Slots | |
| M.2 | 1 |
LED / Controls | |
| LED | Power LED |
| Controls | On/Off |
Connectors | |
| Connectors | 2xDB9, RJ45 Ethernet, DC Input, HDMI, 3xUSB |
System Power Input | |
| Input Voltage DC | 12...12 V |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
Software | |
| Operating System Compatibility | Windows 10, Linux OS |
Dimensions and weight | |
| Width | 201.4 mm |
| Height | 138.9 mm |
| Depth | 38.28 mm |
Operating Conditions | |
| Operating Temperature | -10...50 °C |
| Humidity | 10-90% |
| Vibration | MIL-STD-810G 514.5C-1 |
| Shock | 5G; 11ms; 100 shocks per axis |
Standards and Certifications | |
| Certifications | CE, FCC |
