Construction | |
| Construction Chassis | Heavy-Duty Steel Chassis |
| Mounting Configuration | 19" Rackmount |
| Height | 2 U |
CPU | |
| Socket | LGA2011 |
| CPU Support Type | Xeon |
| Number of CPU | 2 |
Chipset | |
| Chipset | Intel C612 |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 8xDIMM |
| ECC | Yes |
| Maximum Memory | 256 GB |
Graphic | |
| Graphic Controller | Aspeed AST2400 |
| Graphic Memory Size | 0.06 GB |
| Interfaces | VGA |
Ethernet | |
| Controller Type | Intel i210-AT |
| Total Ethernet | 4 |
| 10/100/1000 Mbit/s | 4 |
Interfaces | |
| USB Total | 4 |
| USB 2.0 | 2 |
| USB v3.x | 2 |
Storage Cage | |
| 2.5" Cage External | 8 |
Extension Slots | |
| PCI Express x16 | 4 |
| PCI Express x8 | 1 |
LED / Controls | |
| LED | 1xHDD LED, Power LED, FAULT LED, LAN LED |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | DB15 VGA, RJ45 Ethernet, 4xUSB |
System Power Input | |
| Input Voltage AC | 100...240 V |
Power Supply | |
| Type of Power Supply | Redundant |
Dimensions and weight | |
| Width | 430 mm |
| Height | 88 mm |
| Depth | 798 mm |
Operating Conditions | |
| Operating Temperature | 0...40 °C |
| Vibration | 0.5 Grms |
| Shock | 10 G |
Standards and Certifications | |
| Certifications | CE, FCC |
