Construction | |
| Construction Chassis | Metal Chassis |
| Type | Fan |
CPU | |
| СPU Generation/Family | Skylake |
| Socket | LGA1151 |
| CPU Support Type | Core i3, Core i5, Core i7, Pentium |
Chipset | |
| Chipset | Intel H110 |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 1xSODIMM |
| ECC | No |
| Maximum Memory | 32 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
| Interfaces | DVI-D, VGA |
Ethernet | |
| Controller Type | Intel i219-LM, Intel i210-AT |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 2 |
| RS-232/422/485 | 2 |
| USB Total | 4 |
| USB v3.x | 4 |
Audio | |
| Audio Controller | Intel HD Audio |
Drive interfaces | |
| SATA 3 | 1 |
| CFast Slots | 1 |
Storage Cage | |
| Number Of Cage External | 1 |
| 2.5" Cage Intenal | 1 |
Extension Slots | |
| Total | 3 |
| PCI Express x16 | 1 |
| Mini-PCIe/Mini Card | 1 |
LED / Controls | |
| LED | Power LED |
| Controls | On/Off |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | DVI-D, DB15 VGA, Line Out, 2xDB9, 2xRJ45 |
System Power Input | |
| Input Voltage DC | 19...24 V |
Power Supply | |
| Supported Types of Power Supply | External power adapter AC/DC |
Dimensions and weight | |
| Width | 240 mm |
| Height | 97 mm |
| Depth | 190 mm |
Operating Conditions | |
| Vibration | 0.5Grms. random. 5~500Hz. 3 axes. 1 hr/axis |
| Shock | 10G. half sine wave. 11 ms duration |
Standards and Certifications | |
| Certifications | CE, FCC |
| Safety | CCC, UL |
