System Architecture | |
| Form Factor | Mini-ITX |
Construction | |
| Type | Fanless |
CPU | |
| Processor Installed | AMD GX-224IJ |
| Max CPU frequency | 2.4 GHz |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| ECC | Yes |
| Maximum Memory | 16 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in Chipset |
| Interfaces | DisplayPort, DVI-D, LVDS, HDMI |
Ethernet | |
| Controller Type | Realtek 8111G |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 6 |
| RS-232 | 5 |
| RS-232/422/485 | 1 |
| USB Total | 4 |
| USB 2.0 | 4 |
| USB v3.x | 4 |
Digital Input-Output | |
| Channels of DIO | 8 |
Drive interfaces | |
| mSATA | 1 |
Extension Slots | |
| Total | 3 |
| PCI Express x4 | 1 |
| M.2 | 1 |
| Mini-PCIe/Mini Card | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | DVI-D, HDMI, 2xRJ45 Ethernet, 4xUSB, DC Input, Display Port |
Dimensions and weight | |
| Width | 170 mm |
| Length | 170 mm |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
