System Architecture | |
| Form Factor | Mini-ITX |
CPU | |
| СPU Generation/Family | Skylake |
| CPU Support Type | Core i7, Core i5, Core i3, Pentium, Celeron |
| Socket | LGA1151 |
Chipset | |
| Chipset | Intel H110 |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| Maximum Memory | 32 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
| Interfaces | DisplayPort, LVDS, HDMI |
Ethernet | |
| Controller Type | Realtek RTL8111G-CG 10/100/1000Mbps |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Interfaces | |
| COM Total | 1 |
| RS-232/422/485 | 1 |
| USB v3.x | 4 |
Digital Input-Output | |
| Channels of DIO | 8 |
Audio | |
| Audio Controller | Intel HD Audio |
Drive interfaces | |
| mSATA | 1 |
Extension Slots | |
| Total | 1 |
| SIM Card slots | 1 |
| Mini-PCIe/Mini Card | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | HDMI, RJ45 Ethernet, 4xUSB, Mic In, Line Out, DC Input, Display Port |
Software | |
| Operating System Compatibility | Windows Embedded Standard 7, Linux OS, QNX |
Dimensions and weight | |
| Width | 170 mm |
| Length | 170 mm |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
