System Architecture | |
| Form Factor | Mini-ITX |
CPU | |
| Processor Installed | Intel Atom C3958 |
| Max CPU frequency | 2 GHz |
| Number of CPU | 1 |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xDIMM |
| ECC | Yes |
| Maximum Memory | 32 GB |
Graphic | |
| Graphic Controller | Aspeed AST 2500 |
| Interfaces | VGA |
Ethernet | |
| Controller Type | Intel X557-AT2, Marvell 88E1512 10/100/1000 Mbps |
| Total Ethernet | 4 |
| 10/100/1000 Mbit/s | 2 |
| 10 Gbit/s | 2 |
Interfaces | |
| COM Total | 2 |
| RS-232 | 1 |
| RS-232/422/485 | 1 |
| USB Total | 4 |
| USB 2.0 | 1 |
| USB v3.x | 3 |
Extension Slots | |
| Total | 2 |
| PCI Express x8 | 1 |
| Mini-PCIe/Mini Card | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Internal Ports | COM, 24-pin ATX, 6-pin KB/MS, 4-pin ATX |
| Connectors | DB15 VGA, 4xRJ45 Ethernet, 4xUSB, DB9 Female |
Dimensions and weight | |
| Width | 170 mm |
| Length | 170 mm |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
