System Architecture | |
| Form Factor | Micro ATX |
CPU | |
| CPU Support Type | Core i7, Core i5, Core i3, Xeon, Celeron, Pentium |
| Socket | LGA1151 |
| Number of CPU | 1 |
Chipset | |
| Chipset | Intel C236 |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xDIMM |
| ECC | Yes |
| Maximum Memory | 64 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
| Interfaces | DisplayPort, DVI-D, HDMI, VGA |
Ethernet | |
| Controller Type | Intel i211, Intel i219-LM |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 2 |
| RS-232 | 2 |
| RS-422/485 | 1 |
| USB Total | 12 |
| USB 2.0 | 2 |
| USB v3.x | 10 |
Audio | |
| Audio Controller | Realtek ALC892 |
Drive interfaces | |
| mSATA | 1 |
Extension Slots | |
| Total | 3 |
| PCI Express x16 | 1 |
| PCI Express x4 | 1 |
| Mini-PCIe/Mini Card | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | DVI-D, DB15 VGA, HDMI, 2xRJ45 Ethernet, 8xUSB, Mic In, Line Out, Display Port |
Software | |
| Operating System Compatibility | Windows Embedded Standard 7, Windows Embedded Standart 8.1, Windows IoT Enterprise 10 |
Dimensions and weight | |
| Width | 244 mm |
| Length | 244 mm |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
