System Architecture | |
| Form Factor | ATX |
CPU | |
| СPU Generation/Family | Comet Lake |
| CPU Support Type | Celeron, Core i3, Core i5, Core i7, Pentium, Core i9 |
| Socket | LGA1200 |
Chipset | |
| Chipset | Intel H420E |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xDIMM |
| Maximum Memory | 64 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
| Interfaces | DVI-D, VGA |
Ethernet | |
| Controller Type | Intel i211-AT 10/100/1000 Mbps, Intel i219-V 10/100/1000 Mbps |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 6 |
| RS-232 | 5 |
| RS-232/422/485 | 1 |
| USB Total | 10 |
| USB 2.0 | 4 |
| USB v3.x | 6 |
Drive interfaces | |
| M.2 | 1 |
Extension Slots | |
| Total | 7 |
| PCI Express x16 | 1 |
| PCI Express x4 | 2 |
| M.2 | 1 |
| PCI | 4 |
Connectors | |
| Internal Ports | 4xSATA 3, 4xUSB 2.0, 24-pin ATX, 1x14-pin RS-232/422/485, 3x10-pin RS-232, GPIO |
| Connectors | 2xDB9, DVI-I, DB15 VGA, 2xRJ45 Ethernet, 6xUSB, Mic In, Line Out |
Dimensions and weight | |
| Width | 244 mm |
| Length | 305 mm |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
