System Architecture | |
| Form Factor | ATX |
CPU | |
| СPU Generation/Family | Alder Lake, Coffee Lake |
| CPU Support Type | Celeron, Core i3, Core i5, Core i7, Pentium, Core i9 |
| Socket | LGA1700 |
Chipset | |
| Chipset | Intel Q670E |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 4xDIMM |
| Maximum Memory | 128 GB |
Graphic | |
| Graphic Controller | Integrated in Chipset |
| Interfaces | DisplayPort, HDMI, VGA |
Ethernet | |
| Controller Type | Intel i210-AT, Intel i219-LM |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 6 |
| RS-232 | 5 |
| RS-232/422/485 | 1 |
| USB Total | 14 |
| USB 2.0 | 8 |
| USB v3.x | 6 |
Audio | |
| Audio Controller | Realtek ALC888 |
Drive interfaces | |
| SATA 3 | 4 |
| RAID Levels | 1, 5, 10, 0 |
| M.2 | 1 |
Extension Slots | |
| Total | 7 |
| PCI Express x16 | 1 |
| PCI Express x8 | 1 |
| PCI Express x4 | 3 |
| PCI | 2 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Internal Ports | 4xSATA 3, 8-pin ATX, 24-pin ATX, 19-pin USB 3.0, 2xUSB 2.0, 3x10-pin RS-232, 1x14-pin RS-232/422/485, 2x4-pin USB 2.0, GPIO |
| Connectors | DB9, DB15 VGA, HDMI, Display Port, 8xUSB, 2xRJ45 Ethernet, Mic In, Line Out |
Software | |
| Operating System Compatibility | Windows 11 |
Dimensions and weight | |
| Width | 305 mm |
| Length | 244 mm |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
