CPU | |
| СPU Generation/Family | Tiger Lake |
Memory | |
| ECC | Yes |
| Maximum Memory | 32 GB |
Graphic | |
| Graphic Controller | Intel Iris Xe Graphics |
Ethernet | |
| Controller Type | Intel i219, Intel i225V |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 1 |
| 2,5 Gbit/s | 1 |
Interfaces | |
| COM Total | 4 |
| RS-232 | 2 |
| RS-232/422/485 | 2 |
| USB Total | 4 |
Digital Input-Output | |
| Channels of DIO | 16 |
Industrial Interfaces | |
| CAN Port | 1 |
Drive interfaces | |
| RAID Levels | 1 |
Storage Cage | |
| 2.5" Cage External | 2 |
Extension Slots | |
| Total | 2 |
| M.2 | 1 |
| Mini-PCIe/Mini Card | 1 |
Connectors | |
| Connectors | 5xDB9, DB25, HDMI, 2xRJ45, 4xUSB, Mic In, Line In, Line Out, Display Port |
Software | |
| Operating System Compatibility | Linux OS, Windows 10 |
Dimensions and weight | |
| Width | 220 mm |
| Height | 73 mm |
| Depth | 175 mm |
Operating Conditions | |
| Vibration | SSD : 5Grms. 5Hz to 500Hz. 3 Axis |
| Shock | SSD : 50G @ wallmount. Half-sine. 11ms |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
| Vehicle | E-Mark |
| Vibration And Shock | IEC 60068-2-27, IEC 60068-2-64 |
