Specification
Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | DIN-Rail mount |
Ethernet | |
| Total Ethernet | 2 |
Supported Protocols | |
| Industrial Protocols | EtherCAT slave |
Digital Input | |
| Number of channels | 4 |
| Signal Type | CW/CCW, AB Phase |
| Max frequency | 10 kHz |
Digital Output | |
| Channels | 4 |
| Signal Type | CW/CCW, Pulse/Dir |
| Output frequency range | 0~5 MHz |
System Power Input | |
| Input Voltage DC | 24...24 V |
Dimensions and weight | |
| Width | 153 mm |
| Depth | 53 mm |
| Height | 90 mm |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
