System Architecture | |
| Form Factor | Mini-ITX |
CPU | |
| СPU Generation/Family | Coffee Lake |
| CPU Support Type | Celeron, Core i3, Core i5, Core i7, Pentium |
| Socket | LGA1151 |
Chipset | |
| Chipset | Intel Q370 |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| ECC | Yes |
| Maximum Memory | 32 GB |
Graphic | |
| Graphic Controller | Integrated in CPU |
| Interfaces | DisplayPort, DVI-D, HDMI |
Ethernet | |
| Controller Type | Realtek RTL8111G-CG 10/100/1000Mbps |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 4 |
| RS-232 | 3 |
| RS-232/422/485 | 1 |
| USB Total | 8 |
| USB 2.0 | 2 |
| USB v3.x | 6 |
Drive interfaces | |
| RAID Levels | 1, 5, 10 |
| M.2 | 1 |
Extension Slots | |
| Total | 2 |
| PCI Express x16 | 1 |
| Mini-PCIe/Mini Card | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Internal Ports | 4xSATA 3, 24-pin ATX, 4x10-pin RS-232, 2x4-pin USB 2.0, GPIO |
| Connectors | DB9, DVI-D, HDMI, 2xRJ45 Ethernet, 4xUSB, Mic In, Line In, Line Out, Display Port |
Software | |
| Operating System Compatibility | Linux OS, Ubuntu, Fedora, Windows 10 |
Dimensions and weight | |
| Width | 170 mm |
| Length | 170 mm |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
Standards and Certifications | |
| Certifications | CE, FCC Class B |
