Specification
Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | Built-in |
Analog Input | |
| Total channels of analog input | 12 |
| Number of Bits | 16 Bit |
| Voltage range | +/-150 mV, +/-500 mV, +/-1 V, +/-5 V, +/-10 V |
| Current range | 0...20 mA, 4...20 mA, -20...+20 mA |
| Sampling rate | 12 Hz |
| Differential channels | 12 |
Expansion Module | |
| io_type | ai |
Connectors | |
| Connectors | Screw Terminal |
Dimensions and weight | |
| Width | 30 mm |
| Depth | 100 mm |
| Height | 139 mm |
Operating Conditions | |
| Operating Temperature | -10...60 °C |
