Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | Wall |
| Protection Level of Front Side (Panel) | IP65 |
Display | |
| Display Type | LCD TFT |
| Diagonal | 17.3 " |
| Brightness | 300 Cd/m2 |
| Contrast Ratio | 650~1 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| Processor Installed | Intel Pentium N4200 |
Memory | |
| Socket Type | 2xSODIMM 204pin |
| ECC | No |
| Maximum Memory | 16 GB |
Ethernet | |
| Controller Type | Intel i211-AT 10/100/1000 Mbps |
| 10/100/1000 Mbit/s | 1 |
Wi-Fi | |
| Wi-Fi Standard | Yes |
Interfaces | |
| USB Total | 4 |
Audio | |
| Audio Controller | Realtek ALC662 |
Extension Slots | |
| Mini-PCIe/Mini Card | 1 |
Connectors | |
| Connectors | HDMI, RJ45 Ethernet, 4xUSB, 2xDisplayPort |
Software | |
| Operating System Compatibility | Windows 10 |
Dimensions and weight | |
| Width | 445 mm |
| Height | 281 mm |
| Depth | 45 mm |
Operating Conditions | |
| Vibration | With SSD/mSATA : 1.5Grms. IEC 60068-2-64. Random. 5 ~ 500Hz. 30min/axis |
| Shock | With CF/SSD : 10Grms. IEC 60068-2-27. Half Sine. 11ms |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
