Construction | |
| Construction Chassis | Metal Chassis, Aluminium Chassis |
| Mounting Configuration | Built-in, Desktop, Wall |
| Type | Fanless |
CPU | |
| СPU Generation/Family | Skylake |
| Socket | CPU onboard |
| CPU Support Type | Celeron, Core i3, Core i5, Core i7 |
Chipset | |
| Chipset | Intel SoC |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 1xSODIMM |
| ECC | No |
| Maximum Memory | 16 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
| Interfaces | VGA |
Ethernet | |
| Controller Type | Intel i211-AT 10/100/1000 Mbps, Intel i219-LM |
| Total Ethernet | 5 |
| 10/100/1000 Mbit/s | 1 |
| PoE+ 10/100/1000 Mbit/s | 4 |
Interfaces | |
| COM Total | 2 |
| RS-232 | 2 |
| USB Total | 5 |
| USB 2.0 | 1 |
| USB v3.x | 4 |
Digital Input-Output | |
| Channels of DIO | 32 |
Digital Input | |
| Isolation DIO | Yes |
Drive interfaces | |
| SATA 3 | 1 |
| mSATA | 1 |
Storage Cage | |
| Number Of Cage External | 1 |
| 2.5" Cage Intenal | 1 |
Extension Slots | |
| Total | 1 |
| Mini-PCIe/Mini Card | 1 |
LED / Controls | |
| LED | Power LED, 1xHDD LED |
| Controls | On/Off |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | 2xDB9, DB15 VGA, 5xRJ45 Ethernet, 4xUSB, 2xSFP, DC input (terminal block), DIO (terminal block) |
System Power Input | |
| Input Voltage DC | 9...36 V |
| Power Consumption | 60 W |
Power Supply | |
| Supported Types of Power Supply | External power adapter AC/DC |
Software | |
| Operating System Compatibility | Linux kernel 3.x, Ubuntu, Windows IoT Enterprise 10 |
Dimensions and weight | |
| Width | 195 mm |
| Height | 90 mm |
| Depth | 140 mm |
Operating Conditions | |
| Operating Temperature | 0...55 °C |
| Humidity | 10-95% |
| Vibration | 5~500Hz 3 Grms X.Y.Z axis w/ mSATA. according to IEC 68-2-64 |
| Shock | 10G peak acceleration (11 m sec. duration). operation; 30G peak acceleration (11 m sec. duration). nonoperation; According to IEC 68-2-27 |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
