Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Desktop, Wall |
| Type | Fanless |
CPU | |
| Processor Installed | Intel Core i5-8365UE |
| Max CPU frequency | 4.1 GHz |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| Maximum Memory | 32 GB |
Graphic | |
| Graphic Controller | Intel GT2-4400 |
Ethernet | |
| Controller Type | Intel i218 10/100/1000 Mbps, Intel i210 10/100/1000 Mbps |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 3 |
| RS-232 | 1 |
| RS-232/422/485 | 2 |
| USB Total | 4 |
| USB 2.0 | 2 |
| USB v3.x | 2 |
Audio | |
| Audio Controller | Realtek ALC888 |
Drive interfaces | |
| mSATA | 1 |
Storage Cage | |
| Number Of Cage External | 1 |
| 2.5" Cage External | 1 |
Extension Slots | |
| Total | 2 |
| Mini-PCIe/Mini Card | 2 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | 3xDB9, DB15 VGA, LVDS, HDMI, 2xRJ45 Ethernet, 4xUSB, Mic In, Line In, Line Out, DC Input, DB9 GPIO |
System Power Input | |
| Input Voltage DC | 12...12 V |
Software | |
| Operating System Compatibility | Windows 7, Windows Embedded Standard 7, Windows 8, Windows Embedded Standard 8 |
Dimensions and weight | |
| Width | 195 mm |
| Height | 55 mm |
| Depth | 140 mm |
Operating Conditions | |
| Operating Temperature | -20...55 °C |
| Vibration | mSATA/SSD: 5 Grms. IEC 60068-2-64. random. 5...500 Hz. 1 hr/axis |
| Shock | mSATA/SSD: 50 G. IEC 60068-2-27. half sine. 11 ms duration |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
| Safety | CCC, CB, UL, BSMI |
| Vibration And Shock | IEC 60068-2-27, IEC 60068-2-64 |
