Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Desktop, Wall, DIN-Rail mount, Wall VESA 75 |
| Type | Fanless |
CPU | |
| Processor Installed | Intel Atom E3845 |
| Max CPU frequency | 1.91 GHz |
Chipset | |
| Chipset | Intel Atom SoC |
Memory | |
| Form-factor | DDR3L |
| Socket Type | 1xSODIMM |
| Maximum Memory | 8 GB |
Graphic | |
| Graphic Controller | Intel Gen7 graphic engine |
Ethernet | |
| Controller Type | Intel i210-IT |
| Total Ethernet | 6 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 2 |
| RS-232/422/485 | 2 |
| USB Total | 4 |
| USB 2.0 | 3 |
| USB v3.x | 1 |
Digital Input-Output | |
| Channels of DIO | 8 |
Digital Input | |
| Isolation DIO | Yes |
Industrial Interfaces | |
| CAN Port | 2 |
Audio | |
| Audio Controller | Realtek ALC888 |
Drive interfaces | |
| mSATA | 1 |
Storage Cage | |
| 2.5" Cage External | 1 |
Extension Slots | |
| Total | 4 |
| Mini-PCIe/Mini Card | 4 |
| SIM Card slots | Yes, 2 |
Additional Functions | |
| GPS | GPS |
| Watchdog timer type | Software |
Connectors | |
| Connectors | DB15 VGA, HDMI, 4xRJ45, 2xRJ45 Ethernet, 4xUSB, Audio (in/out/Mic), DC input (terminal block), DIO (terminal block) |
System Power Input | |
| Input Voltage DC | 9...36 V |
Software | |
| Operating System Compatibility | Windows 7, Windows Embedded Standard 7, Windows 8, Windows Embedded Standard 8, Linux OS |
Dimensions and weight | |
| Width | 264.5 mm |
| Height | 69.2 mm |
| Depth | 133 mm |
Operating Conditions | |
| Operating Temperature | -30...60 °C |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
| Safety | CCC, UL, BSMI |
