Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Wall, DIN-Rail mount, Wall VESA 75 |
| Type | Fanless |
CPU | |
| СPU Generation/Family | Bay Trail |
| Processor Installed | Intel Atom E3845 |
| Max CPU frequency | 1.91 GHz |
Chipset | |
| Chipset | Intel Bay Trail-I SoC |
Memory | |
| Form-factor | DDR3L |
| Socket Type | 1xSODIMM |
| Maximum Memory | 8 GB |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Controller Type | Intel i210-IT |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| RS-232/422/485 | 2 |
| USB 2.0 | 3 |
| USB v3.x | 1 |
Audio | |
| Audio Controller | Realtek ALC888 |
Drive interfaces | |
| mSATA | 1 |
Storage Cage | |
| 2.5" Cage External | 1 |
Extension Slots | |
| Mini-PCIe/Mini Card | 4 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | DB15 VGA, HDMI, 2xRJ45 Ethernet, 4xUSB, Audio Out, Mic In, 2xDB15 GPIO, Audio In, 4xM12 PoE |
System Power Input | |
| Input Voltage DC | 9...36 V |
| Power Consumption | 16 W |
Power Supply | |
| Type of Power Supply | AT, ATX |
Dimensions and weight | |
| Width | 264.5 mm |
| Height | 69.2 mm |
| Depth | 133 mm |
Operating Conditions | |
| Operating Temperature | 0...45 °C |
| Vibration | 3 Grms. 5 ~ 500 Hz. 1 hr/axis |
| Shock | 30 G. 11 ms duration |
Standards and Certifications | |
| Certifications | CE, FCC Class A, CB |
| Safety | CCC, UL, BSMI |
| Vibration And Shock | IEC 60068-2-27, IEC 60068-2-64 |
