Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Built-in, Wall, DIN-Rail mount |
| Type | Fanless |
CPU | |
| СPU Generation/Family | Apollo Lake |
| Processor Installed | Intel Atom E3940 |
| Socket | CPU onboard |
| Max CPU frequency | 1.8 GHz |
Chipset | |
| Chipset | Intel Atom SoC |
Memory | |
| Form-factor | DDR3L |
| Socket Type | 1xSODIMM |
| Maximum Memory | 8 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU, Intel HD Graphics 500 |
Ethernet | |
| Controller Type | Intel i210 10/100/1000 Mbps |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 4 |
| RS-232 | 2 |
| RS-232/422/485 | 2 |
| USB Total | 6 |
| USB 2.0 | 4 |
| USB v3.x | 2 |
Digital Input-Output | |
| Channels of DIO | 8 |
Audio | |
| Audio Controller | Realtek ALC888 |
Drive interfaces | |
| mSATA | 1 |
Storage Cage | |
| Number Of Cage External | 1 |
| 2.5" Cage Intenal | 1 |
Extension Slots | |
| Total | 2 |
| M.2 | 1 |
| Mini-PCIe/Mini Card | 1 |
| SIM Card slots | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | 4xDB9, DB15 VGA, HDMI, 2xRJ45 Ethernet, 5xUSB, Line In, Line Out, DC Input, DB9 DIO |
System Power Input | |
| Input Voltage DC | 12...12 V |
| Power Consumption | 19.76 W |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
| Output Power | 60 W |
Software | |
| Operating System Compatibility | Windows 10 |
Dimensions and weight | |
| Width | 260 mm |
| Height | 44 mm |
| Depth | 140.2 mm |
Operating Conditions | |
| Operating Temperature | -20...60 °C |
Standards and Certifications | |
| Certifications | CE, FCC Class B |
| Safety | CCC, CB, UL, BSMI |
| Vibration And Shock | IEC 60068-2-27, IEC 60068-2-64 |
