Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Built-in, Desktop, Wall |
| Type | Fanless |
CPU | |
| Processor Installed | Intel Core i7-6822EQ |
| Socket | CPU onboard |
| Max CPU frequency | 2.8 GHz |
Chipset | |
| Chipset | Intel QM170 PCH |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| Maximum Memory | 32 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Controller Type | Intel i210 10/100/1000 Mbps, Intel i219-IT |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 3 |
| RS-232/422/485 | 3 |
| USB Total | 3 |
| USB v3.x | 3 |
Digital Input | |
| Isolation DIO | Yes |
Audio | |
| Audio Controller | Realtek ALC888 |
Drive interfaces | |
| mSATA | 1 |
Storage Cage | |
| Number Of Cage External | 1 |
| 2.5" Cage External | 1 |
Extension Slots | |
| Total | 3 |
| M.2 | 1 |
| Mini-PCIe/Mini Card | 2 |
| SIM Card slots | 2 |
Additional Functions | |
| GPS | GPS |
| Watchdog timer type | Software |
Connectors | |
| Connectors | 5xDB9, DB15 VGA, HDMI, 2xRJ45 Ethernet, 3xUSB, Audio (in/out/Mic), DC Input, 12V DC Output, 2xSIM Card Slot |
System Power Input | |
| Input Voltage DC | 9...36 V |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
| Output Power | 150 W |
Software | |
| Operating System Compatibility | Windows 7, Windows Embedded Standard 7, Windows 8, Windows Embedded Standard 8, Linux OS, Windows 10 |
Dimensions and weight | |
| Width | 260 mm |
| Height | 73 mm |
| Depth | 160.2 mm |
Operating Conditions | |
| Operating Temperature | -20...70 °C |
Standards and Certifications | |
| Certifications | CE, FCC Class B |
| MIL-STD-810 | MIL-STD-810G Test Method 514.6 Vibration, MIL-STD-810G Test Method 516.6 Shock |
| Safety | CCC, CB, UL, BSMI |
