Construction | |
| Construction Chassis | Aluminium Chassis |
Display | |
| Display Type | LCD TFT |
| Diagonal | 17.3 " |
| Maximum resolution | 1920x1080 Dots |
CPU | |
| Processor Installed | Intel Core i5-9500E |
| Max CPU frequency | 4.2 GHz |
Chipset | |
| Chipset | Intel Q370 |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| Default on Board Memory | 16 GB |
| Maximum Memory | 32 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Controller Type | Intel i210-AT, Intel i219-LM |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 2 |
| RS-232/422/485 | 2 |
| USB Total | 6 |
| USB v3.x | 6 |
Audio | |
| Audio Controller | Realtek ALC888 |
Storage Cage | |
| 2.5" Cage External | 1 |
Installed drive | |
| Drive Type | SSD |
| Storage Form-Factor | 2.5" |
| Drive Interface | SATA |
| 1st Storage Capacity | 240 GB |
Extension Slots | |
| Total | 3 |
| PCI Express x8 | 2 |
| PCI Express x4 | 1 |
Keyboard / Pointing Devices | |
| Type Keyboard | Industrial |
| Number of Keys | 104 |
| Layout | English, Russian |
| Type Mouse | TouchPad |
Connectors | |
| Connectors | 2xDB9, DVI-D, HDMI, 6xUSB, Mic In, Line In, Line Out, Display Port |
System Power Input | |
| Input Voltage AC | 100...240 V |
Power Supply | |
| Type of Power Supply | Industrial |
| Output Power | 400 W |
Software | |
| Operating System Compatibility | Windows 10 |
Dimensions and weight | |
| Width | 418 mm |
| Height | 166.2 mm |
| Depth | 352 mm |
Operating Conditions | |
| Operating Temperature | 0...40 °C |
Standards and Certifications | |
| Certifications | CE |
