Construction | |
| Construction Chassis | Metal Chassis with Aluminium Heatsink |
| Mounting Configuration | Panel, Wall VESA 100 |
| Protection Level of Front Side (Panel) | IP65 |
| Type | Fanless |
Display | |
| Display Type | LCD TFT |
| Diagonal | 15.6 " |
| Maximum resolution | 1366x768 Dots |
| Aspect Ratio | 16:9 |
| Brightness | 400 Cd/m2 |
| Input Interface | DisplayPort, HDMI |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| СPU Generation/Family | Tiger Lake |
| Processor Installed | Intel Core i5-1145G7E |
| Socket | FCBGA 1449 |
| Max CPU frequency | 4.1 GHz |
Chipset | |
| Chipset | Intel SoC |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| ECC | No |
| Default on Board Memory | 4 GB |
| Maximum Memory | 64 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Controller Type | Intel i211-AT 10/100/1000 Mbps, Intel i226-LM |
| Total Ethernet | 3 |
| 10/100/1000 Mbit/s | 2 |
| 2,5 Gbit/s | 1 |
Interfaces | |
| COM Total | 3 |
| RS-232 | 1 |
| RS-232/422/485 | 2 |
| USB Total | 4 |
| USB v3.x | 4 |
Digital Input-Output | |
| Channels of DIO | 16 |
Digital Input | |
| Isolation DIO | Yes |
Drive interfaces | |
| SATA 3 | 1 |
| M.2 | 1 |
Storage Cage | |
| 2.5" Cage Intenal | 1 |
Extension Slots | |
| Total | 4 |
| M.2 | 3 |
| M.2 Form Factor | 2280 M, 2242 M, 3042 B, 3052 B, 2230 E |
| Mini-PCIe/Mini Card | 1 |
Antenna characteristics | |
| Cellular interfaces | 4G (Optional) |
LED / Controls | |
| Controls | On/Off, 1xReset |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | 3xDB9, HDMI, 3xRJ45 Ethernet, 4xUSB, Mic In, Line Out, DC input (terminal block), 2xDIO (terminal block), Display Port |
System Power Input | |
| Input Voltage DC | 9...36 V |
Power Supply | |
| Supported Types of Power Supply | External power adapter AC/DC |
Software | |
| Operating System Compatibility | Windows 10, Windows 11, Ubuntu 20.04 |
Dimensions and weight | |
| Width | 404 mm |
| Height | 255 mm |
| Depth | 65.8 mm |
Operating Conditions | |
| Operating Temperature | -20...55 °C |
| Humidity | 5-95% |
| Vibration | 5 ~ 500Hz. 1Grms random (w/ SSD) |
| Shock | Operating 10G. 11ms non-operating 30G. 11ms (w/ SSD) |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
