System Architecture | |
| Form Factor | ATX |
CPU | |
| СPU Generation/Family | Comet Lake |
| CPU Support Type | Core i3, Core i5, Core i7, Core i9, Xeon |
| Socket | LGA1200 |
Chipset | |
| Chipset | Intel W480E |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 4xDIMM |
| ECC | Yes |
| Maximum Memory | 128 GB |
Graphic | |
| Graphic Controller | Integrated in CPU |
| Interfaces | DVI-D, HDMI, VGA |
Ethernet | |
| Controller Type | Intel i210-AT, Intel i219 |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 2 |
| RS-232 | 2 |
| USB Total | 9 |
| USB 2.0 | 4 |
| USB v3.x | 5 |
Audio | |
| Audio Controller | Realtek ALC892 |
Drive interfaces | |
| RAID Levels | 1, 5, 10 |
| M.2 | 1 |
Extension Slots | |
| Total | 7 |
| PCI Express x16 | 1 |
| PCI Express x8 | 1 |
| PCI Express x4 | 2 |
| M.2 | 1 |
| PCI | 2 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Internal Ports | LPT, USB 2.0, 24-pin ATX, 2x10-pin RS-232, 3x4-pin USB 2.0, 8-pin ATX, 5xSATA 3 |
| Connectors | DVI-D, DB15 VGA, HDMI, 2xRJ45 Ethernet, Mic In, Line Out |
Software | |
| Operating System Compatibility | Windows 10, Windows Server 2019 |
Dimensions and weight | |
| Width | 244 mm |
| Length | 304.8 mm |
