System Architecture | |
| Form Factor | Extended ATX |
CPU | |
| CPU Support Type | Xeon |
| Socket | LGA 3647-P0 |
| Number of CPU | 2 |
Chipset | |
| Chipset | Intel C622 |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 12xDIMM |
| ECC | Yes |
| Maximum Memory | 768 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Aspeed AST 2500 |
Ethernet | |
| Controller Type | Intel i210-AT |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 1 |
| RS-232 | 1 |
| USB Total | 9 |
| USB 2.0 | 5 |
| USB v3.x | 4 |
Drive interfaces | |
| RAID Levels | 1, 5, 10 |
Extension Slots | |
| Total | 7 |
| PCI Express x16 | 5 |
| PCI Express x8 | 1 |
| PCI | 1 |
Connectors | |
| Internal Ports | 4-pin (12V DC CPU), 24-pin ATX, USB 3.0, 8xSATA 3 |
| Connectors | DB9, DB15 VGA, 2xRJ45 Ethernet, 4xUSB |
Dimensions and weight | |
| Width | 304.8 mm |
| Length | 330.2 mm |
Operating Conditions | |
| Operating Temperature | 0...45 °C |
