Specification
Ethernet | |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Wi-Fi | |
| Wi-Fi Standard | 802.11a/b/g/n |
| Quantity of Wi-Fi | 1 |
Supported Protocols | |
| Managment Protocols | SNTP, BootP, HTTP, LLDP, UDP, DHCP, DNS, SNMP, ARP, Proxy ARP, TCP/IP |
| Security Protocols | Firewall, IP Address Filtering, IEEE 802.1X Network Access Control, HTTPS, RADIUS, ICMP |
LED / Controls | |
| LED | Power LED, Level signal LED, STATE LED, FAULT LED, 10/100/1000M LED, WLAN LED |
| Controls | 1xReset |
| Setup of Operation Mode | Telnet, Console Port, Web-interface |
Connectors | |
| Connectors | Console Port RS-232 (RJ-45) |
System Power Input | |
| Input Voltage DC | 12...48 V |
| Power Supply Reserve input Voltage DC | 12...48 V |
Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
| Protection Level of Chassis | IP30 |
| Type | Fanless |
Dimensions and weight | |
| Width | 58 mm |
| Depth | 70 mm |
| Height | 115 mm |
Operating Conditions | |
| Operating Temperature | -40...75 °C |
Standards and Certifications | |
| EMI | EN 55022, EN 55024, FCC Part 15 Subpart B Class B |
| Safety | UL 60950-1, EN 60950-1 |
