Specification
Ethernet | |
| Total Ethernet | 2 |
| 10/100 Mbit/s | 2 |
| Type 10/100 Mbit/s | RJ-45 |
Interfaces | |
| COM Total | 1 |
| RS-232/422/485 | 1 |
Wi-Fi | |
| Wi-Fi Standard | 802.11a/b/g/n |
| Quantity of Wi-Fi | 1 |
Supported Protocols | |
| Managment Protocols | SNTP, HTTP, UDP, DHCP, DNS, SNMP, ARP, Proxy ARP |
| Reservation protocols | STP, RSTP |
| Security Protocols | Firewall, IP Address Filtering, IEEE 802.1X Network Access Control, HTTPS, RADIUS, ICMP |
LED / Controls | |
| LED | Level signal LED, WLAN LED, LAN LED, COM-ports LED |
| Controls | 1xReset |
| Setup of Operation Mode | Telnet, Console Port, Web-interface |
Connectors | |
| Connectors | 2xRJ45 |
System Power Input | |
| Input Voltage DC | 9...30 V |
| Power Supply Reserve input Voltage DC | 9...30 V |
Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
| Protection Level of Chassis | IP30 |
Dimensions and weight | |
| Width | 26 mm |
| Depth | 77 mm |
| Height | 115.5 mm |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
Standards and Certifications | |
| EMI | FCC Part 15, FCC Part 15 Subpart B Class B |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8 |
| Safety | UL 60950-1, EN 60950-1 |
| Vehicle | E-Mark |
