Specification
Ethernet | |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
| Type 10/100/1000 Mbit/s | 1xRJ-45 |
Wi-Fi | |
| Wi-Fi Standard | 802.11a/b/g/n |
| Quantity of Wi-Fi | 1 |
Supported Protocols | |
| Managment Protocols | SNTP, HTTP, TCP, UDP, DHCP, DNS, SNMP, Proxy ARP, VLAN, ICMP |
| Reservation protocols | STP, RSTP |
| Security Protocols | NAT, Firewall, IP Address Filtering, IEEE 802.1X Network Access Control, HTTPS, RADIUS |
Digital Input | |
| Total channels of digital input | 2 |
Digital Output | |
| Total channels of digital output | 1 |
| Type | Signal Relay |
| Contact rating of relay (Form A) | 1A@24V DC |
LED / Controls | |
| LED | Level signal LED, STATE LED, FAULT LED, PoE LED, WLAN LED, LAN LED, PWR1, PWR2 |
| Controls | 1xReset |
| Setup of Operation Mode | Telnet, Console Port, Web-interface |
Connectors | |
| Connectors | Console Port RS-232 (RJ-45) |
System Power Input | |
| Input Voltage DC | 12...48 V |
| Power Supply Reserve input Voltage DC | 12...48 V |
| Power over Ethernet (PoE) | PoE, IEEE 802.3af |
Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
| Protection Level of Chassis | IP30 |
Dimensions and weight | |
| Width | 52.7 mm |
| Depth | 105 mm |
| Height | 135 mm |
Operating Conditions | |
| Operating Temperature | -25...60 °C |
Standards and Certifications | |
| EMI | CISPR 22 Class, FCC Part 15 Subpart B Class B |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN 61000-6-2, EN 61000-6-4 |
| Explosion safety | ATEX Zone 2 Group II, UL/cUL Class I Division 2 |
| Safety | UL 60950-1, EN 60950-1 |
