Specification
System Architecture | |
| System Bus | PCI-Express x1 |
Digital Input | |
| Total channels of digital input | 32 |
| Isolation DIO | Yes |
| Type | Dry contact, Wet contact |
| Sink/Source | Sink, Source |
| Level of Logic "0" | 0~3 V |
| Level of Logic "1" | 10~30 V |
Digital Output | |
| Total channels of digital output | 32 |
| Type | Open collector |
| Sink/Source | Sink, Source |
| Output voltage | 30~30 V |
| Max. load current | 100 mA |
Connectors | |
| Connectors | DB37 Female |
Software | |
| Operating System Compatibility | Windows 7, Windows 10 |
| Development Software | LabVIEW |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
| Humidity | 10-95% |
