Camera |
| Form Factor | Dome |
| Maximum Resolution | 12 MP |
| Day&Night Mode | IR Cut Filter Remove |
| Video Analytics Functions | Motion Detection, Camera Tamper, Virtual Line, Alert Zone, Abandoned/Removed Object Detection, Shock Detection, Digital auto tracking, Smoke Detection |
| PTZ Control | Preset points, Preset tours |
| Max Resolution Frame rate | 18 fps |
Supported Protocols |
| Managment Protocols | SMTP, HTTP, TCP, UDP, DHCP, DNS, SNMP, IGMP, FTP, NTP, DDNS, ARP, Bonjour, ICMP |
| Reservation protocols | RSTP |
| Security Protocols | Password Protection, IP Address Filtering, IEEE 802.1X Network Access Control, HTTPS |
Digital Input |
| Total channels of digital input | 2 |
Digital Output |
| Total channels of digital output | 2 |
Connectors |
| Connectors | RJ45, DC input (terminal block), MicroSD card slot, Terminal block |
System Power Input |
| Power over Ethernet (PoE) | PoE |
| Power Consumption | 7 W |
Dimensions and weight |
| Height | 71.04 mm |
Operating Conditions |
| Operating Temperature | -40...50 °C |
Standards and Certifications |
| Certifications | CE, FCC |
| EMI | EN 55022 Class B, FCC Part 15 Subpart B Class B |
| EMS | EN 55024 |
| Vandal Resistance | EN 62262, IK10 level |
