Construction |
| Construction Chassis | Metal Chassis with Aluminium Heatsink |
| Mounting Configuration | Desktop, Wall, DIN-Rail mount, Wall VESA 75 |
| Protection Level of Chassis | IP40 |
| Type | Fanless |
CPU |
| Processor Installed | Intel Atom N270 |
| Max CPU frequency | 1.6 GHz |
Memory |
| Form-factor | DDR2 |
| ECC | No |
| Default on Board Memory | 1 GB |
Graphic |
| Graphic Controller | Integrated in Chipset |
Ethernet |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Interfaces |
| COM Total | 2 |
| RS-232 | 2 |
| USB Total | 2 |
| USB 2.0 | 2 |
Drive interfaces |
| CompactFlash Slots | 1 |
Storage Cage |
| Number Of Cage External | 1 |
| 2.5" Cage Intenal | 1 |
Extension Slots |
| Total | 1 |
| Mini-PCIe/Mini Card | 1 |
| SIM Card slots | 1 |
Additional Functions |
| Watchdog timer type | Software |
Connectors |
| Connectors | 2xDB9, DB15 VGA, LVDS, PS/2 Keyboard/Mouse, RJ45 Ethernet, 2xUSB, DC input (terminal block), CompactFlash |
System Power Input |
| Input Voltage DC | 9...36 V |
| Power Consumption | 15 W |
Software |
| Operating System Compatibility | Windows CE 6.0, Windows XP, Windows 7, Windows Embedded Standard 7, Windows Embedded Standard 2009, Linux OS, QNX |
Dimensions and weight |
| Width | 255 mm |
| Height | 50 mm |
| Depth | 152 mm |
Operating Conditions |
| Operating Temperature | -20...70 °C |
Standards and Certifications |
| Certifications | CE, FCC Class A |
| Safety | CCC, UL |
| Vibration And Shock | IEC 60068-2-27, IEC 60068-2-64 |
