Specification
Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
Memory | |
| SRAM | 512 kB |
Installed drive | |
| Flash Memory Capacity | 0.512 MB |
| EEPROM Memory Capacity | 2 kB |
Expansion Module | |
| Quantity of Slots | 2 |
| Supported Module | I-8K series, I-87K series |
Industrial Interfaces | |
| CAN Port | 1 |
Supported Protocols | |
| Industrial Protocols | DeviceNet |
Connectors | |
| Connectors | Screw Terminal |
Dimensions and weight | |
| Width | 95 mm |
| Depth | 91 mm |
| Height | 132 mm |
System Power Input | |
| Input Voltage DC | 10...30 V |
Operating Conditions | |
| Operating Temperature | -25...75 °C |
