System Architecture | |
| Form Factor | 3.5" |
Construction | |
| Type | Fan |
CPU | |
| Processor Installed | AMD Ryzen V1605B |
| Max CPU frequency | 3.6 GHz |
Memory | |
| Socket Type | 1xSODIMM |
| Maximum Memory | 16 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | AMD Radeon RX Vega |
| Interfaces | DisplayPort, LVDS, 2xHDMI |
Ethernet | |
| Controller Type | Realtek 8111G |
| Total Ethernet | 4 |
| 10/100/1000 Mbit/s | 4 |
Interfaces | |
| COM Total | 2 |
| RS-232 | 1 |
| RS-232/422/485 | 1 |
| USB Total | 4 |
| USB 2.0 | 2 |
| USB v3.x | 2 |
Digital Input-Output | |
| Channels of DIO | 8 |
Drive interfaces | |
| SATA 3 | 1 |
| M.2 | 1 |
Extension Slots | |
| M.2 | 1 |
Connectors | |
| Internal Ports | 2xCOM, 2xUSB 2.0, 10-pin DIO |
| Connectors | 2xHDMI, 4xRJ45, 2xUSB, Display Port |
Software | |
| Operating System Compatibility | Windows 10 |
Dimensions and weight | |
| Width | 104 mm |
| Length | 146 mm |
Operating Conditions | |
| Operating Temperature | -20...60 °C |
Standards and Certifications | |
| Certifications | CE |
