System Architecture | |
| Form Factor | 3.5" |
Construction | |
| Type | Fan |
CPU | |
| Processor Installed | AMD Ryzen V1807B |
| Max CPU frequency | 3.8 GHz |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 1xSODIMM |
| Maximum Memory | 16 GB |
| Assembly | Removable |
Ethernet | |
| Controller Type | Realtek RTL8111G-CG 10/100/1000Mbps |
| Total Ethernet | 3 |
| 10/100/1000 Mbit/s | 3 |
Interfaces | |
| COM Total | 2 |
| RS-232 | 1 |
| USB Total | 4 |
| USB 2.0 | 2 |
| USB v3.x | 2 |
Drive interfaces | |
| M.2 | 1 |
Extension Slots | |
| M.2 | 2 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Internal Ports | COM, SATA 3, USB 2.0 |
| Connectors | HDMI, RJ45, Display Port, USB type A |
Dimensions and weight | |
| Width | 146 mm |
| Length | 104 mm |
Operating Conditions | |
| Operating Temperature | -20...60 °C |
Standards and Certifications | |
| Certifications | CE |
