System Architecture | |
| Form Factor | 3.5" |
Construction | |
| Type | Fanless |
CPU | |
| СPU Generation/Family | Elkhart Lake |
| Processor Installed | Atom x6413E |
| Max CPU frequency | 3 GHz |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 1xSODIMM |
| Maximum Memory | 32 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Intel UHD Graphics |
| Interfaces | DisplayPort, LVDS, HDMI |
Ethernet | |
| Controller Type | Intel i211-AT 10/100/1000 Mbps, Intel i225LM |
| Total Ethernet | 2 |
| 2,5 Gbit/s | 1 |
Interfaces | |
| COM Total | 4 |
| RS-232 | 2 |
| RS-232/422/485 | 2 |
| USB Total | 6 |
| USB 2.0 | 4 |
| USB v3.x | 2 |
Digital Input-Output | |
| Channels of DIO | 8 |
Drive interfaces | |
| SATA 3 | 1 |
| mSATA | 1 |
Extension Slots | |
| M.2 | 2 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | HDMI, 2xRJ45, 4xUSB, Display Port |
Software | |
| Operating System Compatibility | Windows 10 |
Dimensions and weight | |
| Width | 146 mm |
| Length | 104 mm |
Operating Conditions | |
| Operating Temperature | -40...85 °C |
Standards and Certifications | |
| Certifications | CE |
