System Architecture | |
| Form Factor | 3.5" |
Construction | |
| Type | Fanless |
CPU | |
| СPU Generation/Family | Bay Trail |
| Processor Installed | Intel Celeron J1900 |
| Socket | CPU onboard |
| Max CPU frequency | 2.42 GHz |
| Number of CPU | 1 |
Chipset | |
| Chipset | Intel Bay Trail-I SoC |
Memory | |
| Form-factor | DDR3L |
| Socket Type | 1xSODIMM |
| ECC | No |
| Maximum Memory | 8 GB |
| Assembly | Removable |
Graphic | |
| Interfaces | DisplayPort, LVDS, VGA |
Ethernet | |
| Controller Type | Intel i211-AT 10/100/1000 Mbps |
| Total Ethernet | 3 |
| 10/100/1000 Mbit/s | 3 |
Interfaces | |
| COM Total | 2 |
| RS-232 | 1 |
| RS-232/422/485 | 1 |
| USB Total | 3 |
| USB 2.0 | 2 |
| USB v3.x | 3 |
Digital Input-Output | |
| Channels of DIO | 8 |
Audio | |
| Audio Controller | Realtek ALC662 |
Extension Slots | |
| SIM Card slots | 1 |
| M.2 | 2 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | DB15 VGA, 2xRJ45, 1xUSB, Display Port |
Dimensions and weight | |
| Width | 146 mm |
| Length | 104 mm |
Operating Conditions | |
| Operating Temperature | -20...70 °C |
Standards and Certifications | |
| Certifications | CE |
