System Architecture | |
| System Bus | PC/104-Plus |
Interfaces | |
| COM Total | 4 |
| Isolation of COM Ports | 2 kV (RS-422/485) |
| RS-422/485 | 4 |
Connectors | |
| Connectors | 40-pin connector |
Software | |
| Operating System Compatibility | MS DOS, Linux kernel 2.6, Windows CE 5.0, Windows CE 6.0, Windows Server 2003, Windows Server 2008, Windows XP, Windows XP Embedded, Windows 7, Windows 8, Linux kernel 2.4, Windows 95, Windows 98, Windows ME, Windows NT, Windows 2000, Windows Vista, Windows 8.1, QNX 6 |
Dimensions and weight | |
| Width | 90 mm |
| Depth | 96 mm |
Operating Conditions | |
| Operating Temperature | -40...85 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
| EMI | EN 55022, FCC Part 15, EN 61000-3-2, EN 61000-3-3 |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-4-11, IEC 61000-6-2, EN 55024 |
